Description
Brewtools Unitanks are fermenters made for ambitious homebrewers and small breweries. As part of the Brewtools identity, they have explored new techniques and solutions. This has resulted in a series of high end fermentation tanks with new features and a lot of possibilities.
Key Features:-
– Brewtools PureBlast™ surface inside and out which eliminate the use of wax and polishing compounds and does not require passivation.
– Cooling jacket in the vertical walls offers efficient cooling without the hazzle of cleaning a spiral.
– Many options for connecting accessories like sensors, heaters, carb. stones and other accessories.
– Pressure rated for 2 bar / 30 PSI.
– 8″ TC port on top for easy access.
– 2″ TC dump and racking valves.
Unitanks are designed and manufactured with special attention to safety and quality.
They are tested and certified according to the requirements for PED 2014/68/EU by a third party.
Specifications
Low height w/o acc.: 110 cm
– Max height w/o acc.: 130 cm
– Packaging size: 113 (h) x 52 (w) x 52 (d) cm
– Net weight: 44 Kg
– Gross weight: 50 Kg
– Tank diameter (inside): Ø40 cm
– Gross volume: 86 liter
– Max rec. volume: 80 liter
– Min rec. volume: 20 liter
– Volume, cone: 12 liter
– Material: 1.5mm stainless steel (SS304)
– Operating pressure: 1.0 bar / 15 PSI
– Max pressure: 2.0 bar / 30 PSI
In the box:
– Unitank with adjustable frame
– 1 pcs Analog pressure gauge, TC34mm
– 2 pcs Butterfly-valve, 2″
– 1 pcs Butterfly-valve, 34mm DN20
– 1 pcs Blow-off pipe
– 1 pcs Racking arm 2″
– 1 pcs TC elbow 90°, 2″
– 1 pcs Insulation jacket, black neoprene
– 1 pcs Sample valve, 34mm
– 1 pcs TC Adapter 8″-3″
– 1 pcs TC blind cap, 4″
– 1 pcs TC blind cap 2″
– 2 pcs TC blind cap 1.5″
– 3 pcs TC blind cap 34mm
– 2 pcs TC gasket 8″ lipped
– 2 pcs TC gasket 4″
– 2 pcs TC gasket 2″ 5-pack
– 1 pcs TC gasket 1.5″ 5-pack
– 3 pcs TC gasket 34mm 5-pack
– 1 pcs Tri Clamp 8″
– 1 pcs Tri Clamp 4″
– 5 pcs Tri Clamp 2″
– 2 pcs Tri Clamp 1.5″
– 10 pcs Tri Clamp 34mm
– 1 pcs TC tool
– 4 pcs M10 steel/rubber feet
– 1 pcs TC34mm safety valve (PRV, 2 bar)
– Necessary bolts and parts for assembly
david.bowden (verified owner) –
I have been a fan or unitanks for a while I originally had ssbrewtech versions which are good but these are much more versatile. I have changed to fermenting, conditioning and serving from the same tank and these offer me the ability to do all this including carbonating by fermenting under pressure. The advantage of no transfers is great and I have not had any adverse flavours from this unitank process. I do have a sight glass at the base of the fermenter so I can see I have dumped all the tub and yeast. The quality is the best I have seen in home-brew equipment. The glycol jacket and sanitary heater control the temperature easily.
I am slowly converting my brewery to just having unitanks and these are my first choice.
